| Performance |
|---|
| Chipset | Parade - PS176, VIA/VLI - VL100 | | Supported graphics resolutions | 1280 x 720 (HD 720),1280 x 768,1280 x 800,1360 x 768 (WXGA),1440 x 900 (WXGA+),1600 x 900,1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1600 (WQXGA),3840 x 2160 | | USB connector type | USB Type-C | | USB connector gender | Male | | DVI output | No | | HDMI output | Yes | | DisplayPort output | No | | Number of displays supported | 1 | | HDMI version | 2.0 | | Maximum resolution | 3840 x 2160 pixels | | Refresh rate at maximum resolution | 60 Hz | | Maximum resolution (HDMI) | 3840 x 2160 pixels | | Audio output channels | 7.1 channels | | Certification | CE, FCC, REACH | | Design |
|---|
| Product colour | White | | Housing material | Plastic | | Integrated USB cable | Yes | | USB cable length | 0.1 m | | Technical details |
|---|
| Quantity per master (outer) case | 40 pc(s) | | Master (outer) case width | 33 cm | | Master (outer) case length | 35.8 cm | | Master (outer) case height | 31 cm | | Sustainability certificates | RoHS | | Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C | | Storage temperature (T-T) | -20 - 70 °C | | Operating relative humidity (H-H) | 0 - 90% | | Weight & dimensions |
|---|
| Width | 33 mm | | Depth | 50 mm | | Height | 13 mm | | Weight | 22 g | | Package width | 144 mm | | Package depth | 175 mm | | Package height | 31 mm | | Package weight | 107 g | | Logistics data |
|---|
| Quantity per master (outer) case | 40 pc(s) | | Master (outer) case width | 33 cm | | Master (outer) case length | 35.8 cm | | Master (outer) case height | 31 cm |
|
